≥2000times
1 years
CE/RoHS/UN38.3/MSDS
black or optional
About 8.5kg
Credit Card.Paypal.TT.Escrow.Western Union
L260+w170+h230mm
| Normal performance | |||
| NO | Item | General Parameter | Remark |
| 1 | Model | 18650 3.2Ⅴ20Ah | Single |
| 2 | Casing material for single cell | Nickel plated steel | |
| 3 | Standard capacity(0.2C5A) | 20Ah | |
| 4 | Rated voltage | 12.8V | 3.20V(Work voltage:3.20V) |
| 5 | Max.Charge voltage | 14.6V | 3.65V(Single Ave. charge Voltage) |
| 6 | Cut-off voltage | 10V | 2.50V(Single Ave. Discharge Voltage) |
| 8 | Standard charge current | 10A | 0.5C |
| 9 | charging Time | About 3h | |
| 10 | Max Continuous discharge current | 200A | 10C |
| 11 | Peak discharge current | 600A | 1C 10seconds |
| 12 | Battery dimension | L260*w170*h230mm | |
| 13 | (Approx.)Total weight(Approx.) | About 8.5kg | |
| 14 | (Max, at 1000Hz.)Impedance(Max, at 1000Hz.) | ≤ 20mΩ | |
| 15 | (CC/CV)
Charge method (CC/CV) |
Standard | 0℃~45℃ |
| discharge | -20℃~45℃ | ||
| storage | -20℃~45℃ | ||
one:Professional
We are experienced and professional on various types of lifepo4 battery ,lithium battery ,and kinds of Lithium polymer battery for nearly 20 years
TWO:The excellent battery production capacity battery in china
We equipped the most advanced production machine and modern factory with total 40000 suqare metres , and total 2500 employee. The daily production capacity have over 200000pcs lion cylindrical batter and 200000pcs li-polymer battery.
THREE:Quality First
We have strict production management and quality inspection.we always persist "Quality is our soul of enterprise, service paramount" as enterprise purpose
FOUR :The Excellent Excutive Team
we have established professional customer service center that can support 7*24 hours service for any request or complain from the clients .Our services include R&D pre-support and product usage tracks after sales , and maintain the long-term partnership with clients.
