≥3000times
L195±1*W165±1*H175±1mm
2 years
CE/RoHS/UN38.3/MSDS
gray or optional
approx:6 kg
Credit Card.Paypal.TT.Escrow.Western Union
standard carton package or according to customer's special need
| Normal performance | |||
| NO | Item | General Parameter | Remark |
| Cell | Type | LiFePO4 Battery | |
| Cell Model | LF2770180-25Ah | ||
| Nominal Capacity | 50Ah | Discharge : 1C Cut-off Voltage: 2.5V |
|
| Minimum Capacity | 22Ah | Discharge : 0.2C Cut-off Voltage: 2.5V |
|
| Nominal voltage | 3.2V | ||
| Internal Impedance | ≤2mΩ | ||
| Dimension | MAX. 28*70.5*181mm | 0.5C | |
| Weight | 0.6kg | ||
|
battery pack
|
Pack Method | 4S2P | |
| Nominal Capacity | 50Ah | Discharge : 1C | |
| Minimum Capacity | 10Ah | Discharge : 0.2C | |
| Nominal Voltage | 12.8V | ||
| Energy | 640Wh | ||
| Charge Voltage | 14.6V | ||
| Discharge cut-off voltage | 10.0V | ||
| Charge Method | CC/CV | ||
| Standard Charge Current | 10A | ||
| Max. Charge Current | 30A | ||
| Standard Discharge Current | 10A | ||
| Continues Discharge current | 30A | ||
| Cycle Life | 3000 times | ≥70% | |
| Internal Impedance | ≤75mΩ | ||
| Dimension | L198*W166*H169mm | ±5mm | |
| Output Wire | |||
| Output Connector | |||
| Weight | Approx.6kg | ||
| Storage Temperature | -10°C--45°C | ||
| (CC/CV)
Charge method (CC/CV) |
Standard | 0℃~45℃ | |
| discharge | -20℃~45℃ | ||
| storage | -20℃~45℃ | ||
Features of lifepo4 12v 50ah
Application
1.OEM&ODM manufacturer with various design and one-stop battery solution.
2.Reliable quality; Factory direct price; Complete production lines.
3.Timely and professional pre-sales service and after-sales service.
4.100% test before shipment; Solid package; Fast delivery and stable shipment.
1.Where can I get the price of lifepo4 12v 50ah?
Click "Inquiry Now" above or "Leave the Message below". We will offer you the best quote
in 12 hours after we get the product specifications such as voltage capacity application etc
2.How can you guarantee your quality?
Normally we will send you a sample to confirm everything first.Trial oder is available.
And we will make the big order exactly the same as you request.
3.What about the lead time for mass production?
It depends on your order quantity.Normally 1-2days if we have sample in stock,
5-7 days for newly produced samples.10-20 days for big order.
4.What shipping method can I choose? How about the shipping time?
By Express (3-7 working days), suitable for urgent time or small quantity.
By Sea (15-30 days), it suitable for mass production.
By Air (4-7 days), from airport to airport.
