≥2000times
2year
CE/RoHS/UN38.3/MSDS
Credit Card.Paypal.TT.Escrow.Western Union
Customized
standard carton packaging or according customer's special needs
3-7days
| NO. | Item | Specifications | |||||
| 1 | Typical Capacity | 72.0Ah @ 0.2C Discharge | |||||
| Minimum capacity | 68.8Ah @ 0.2C Discharge | ||||||
| 2 | Nominal voltage | 12.8V | |||||
| 3 | Standard Charge | CC/CV,0.2C5A,14.6V | |||||
| 4 | Standard Discharge | CC,0.2C5A, 10.0V | |||||
| 5 | End-of-charge Voltage | 14.6V±0.1V | |||||
| 6 | End-of-charge Current | 0.02C5A (At CV mode) | |||||
| 7 | End-of-discharge Voltage | 10.0V | |||||
| 8 | Charging Time | 8.0hours(standard charge) | |||||
| 9 | Quick Charge Current | 36A (0.5C5rate) | |||||
| 10 | Quick Discharge Current | 72A (1.0C5rate) | |||||
| 11 | Max Discharge Current | 144A (2.0C5rate) | |||||
| 12 | Initial Impedance | Max: 180mW | |||||
| 13 | Weight | Approx:9.50Kg | |||||
| 14 | Operating temperature | Charging: 0℃~45℃
Discharging:-20℃~60℃ |
|||||
| 15 | Storage temperature | -5℃~35℃ | |||||
| 16 | Storage Humidity | ≤75% RH | |||||
| 17 | Appearance | Without scratch, distortion, contamination and leakage | |||||
| 18 | Standard environmental condition | Temperature : 25±2℃
Humidity : 45-75%RH Atmospheric Pressure : 86-106 KPA |
|||||
| 19 | Temperature Dependence of Discharge Capacity
@ 0.2C Discharge |
||||||
| 25℃ | -10℃ | 0℃ | 15℃ | 25℃ | 40℃ | ||
| Relative Capacity | 50% | 80% | 90% | 100% | 100% | ||
our advantage
one:Professional
We are experienced and professional on various types of lifepo4 battery ,lithium battery ,and kinds of Lithium polymer battery for nearly 20 years
TWO:The excellent battery production capacity battery in china
We equipped the most advanced production machine and modern factory with total 40000 suqare metres , and total 2500 employee. The daily production capacity have over 200000pcs lion cylindrical batter and 200000pcs li-polymer battery.
THREE:Quality First
We have strict production management and quality inspection.we always persist "Quality is our soul of enterprise, service paramount" as enterprise purpose
FOUR :The Excellent Excutive Team
we have established professional customer service center that can support 7*24 hours service for any request or complain from the clients .Our services include R&D pre-support and product usage tracks after sales , and maintain the long-term partnership with clients.
