12000mAh
11600mAh
3.7V
≤8h
20.5*74.5*67mm
≤150mΩ
2400mA
192±10 g
2.5V
44.4Wh
|
NO. |
Name |
Condition |
Parameter |
|
| 1 | Norminal capacity | standard charge and discharge（0.2C） | 12000mAh | |
| Minimum capacity | 11600mAh | |||
| 2 | Norminal voltage | 3.7V*n | 3.70V | |
| 3 | Rated Power | 44.4Wh | ||
| 4 | Standard Charge（CC/CV） | CC | Standard charge
0.2ItA |
2400mA |
| Fast charge
0.2ItA |
2400mA | |||
| CV（4.2V*n） | 4.2V | |||
| 5 | Charge time | Standard charge time 0.2ItA | ≤8h | |
| Fast charge time 0.5ItA | ≤3.0h | |||
| 6 | Standard discharge current | 0.2ItA | 2400mA | |
| 7 | Maximum discharge current | 0.2ItA | 2400mA | |
| 9 | Discharge cut-off voltage | 2.5V*n | 2.5V | |
| 10 | Discharge over-current | \ | 3.0～9.0A | |
| 11 | NTC Thermistor value | 25℃ | \ | |
| 12 | Internal resistance | AC 1KHz | ≤150mΩ | |
| 13 | Thermal Fuse | 10A/DC24V | \ | |
| 14 | Storage temperature | 1 month | 0～35℃ | |
| 6 months | 0～25℃ | |||
| 15 | Shipment voltage | \ | ≥3.60V | |
| 16 | Weight | \ | 192±10g | |
| 17 | Dimensions | Length * width * height | 20.5*74.5*67mm | |
