≥500 Times
1 year
CE/RoHS/UN38.3/MSDS
Credit Card.Paypal.TT.Escrow.Western Union
10*34*50mm
cyclenpo
OEM&ODM
Product Specification
|
NO.
|
Item
|
Specifications
|
|
|
1
|
Nominal capacity
|
1800mAh @ 0.2C Discharge
|
|
|
2
|
Initial Impedance
|
Pack ≤50 mΩ
|
|
|
3
|
Nominal voltage
|
3.7V
|
|
|
4
|
Fully charge voltage (FC)
|
4.28V Defined in this DOC: FC = 4.28V
|
|
|
5
|
Fully discharge voltage (FD)
|
3.0V Defined in this DOC: FD = 3.0V
|
|
|
6
|
Charge current
|
0.5=900mA
|
Standard Charging
|
|
1C=1800mA
|
Rapid charge
|
||
|
7
|
Standard charging method
|
0.2C CC ( constant current ) charge to FC, then CV(constant voltage FC)charge till charge current decline to ≤0.01C polymer battery
0.2C CC FC,CV( FC)≤0.01C |
|
|
8
|
charging time
|
6.0 hours(Ref.)
|
Standard Charging
|
|
1 to 1.5hours(Ref.)
|
Rapid charge
|
||
|
9
|
Max. charge current
|
Constant Current 1C Constant Voltage FC 0.01 C cut-off
|
|
|
10
|
Max. discharge current
|
Constant current 1C end voltage FD
|
|
|
11
|
Standard Discharge Current
|
Constant current 0.5 C end voltage FD
|
|
|
12
|
Charge cut-off voltage
|
Ref. 7.1 VDET1
|
|
|
13
|
Discharge cut-off Voltage
|
Ref. 7.1 VDET2
|
|
|
14
|
Operating temperature
|
0℃~45℃
|
Charging
|
|
-20℃~60℃
|
Discharging
|
||
|
15
|
Storage temperature
|
-10℃~ +45℃ less than 1 month
|
Recommended storage temperature: 25℃,at the shipment state
|
|
-10℃~ +35℃ less than 6 months
|
at the shipment state:25℃
|
||
|
16
|
Recoverable capacity
|
Constant current 0.2C charge to FC, then constant voltage FC charge to current declines to 0.01C, rest for 10min,constant current 0.2C discharge to FD,rest for 10min.Repeat above steps 3 times, recording the maximum capacity
|
|
|
17
|
Storage Humidity
|
≤75% RH
|
|
|
18
|
Appearance
|
Without distortion and leakage
|
|
|
19
|
Standard testing condition
|
Temperature: 23±5℃
Humidity : ≤75%RH Atmospheric Pressure : 86-106 Kpa |
|
1.Q:Where can I get the price?
A:We usually quote within 24 hours after we get your inquiry.if you are very urgent to get the price,please call us or tell us in your inquiry priority.
2.Q:how can I get a sample to check your quality?
A:After price confirmation,you can require for samples to check our quality.
3.Q:What about the lead time for mass production?
A:It depends on your order quantity and the season you place the order.
4.Q:What is your team for payment?
A:We accept T/T,L/C,Paypal, Western Union,Money Gram,Ali Express,Cash,etc.
5.Q:What is accepted payment currency?
A:We accepted USD,EUR,CAD,AUD,HKD,GBP,JPY,NZD,SGD,CHF,THB,etc.
6.Q:If we went to test lithium polymer battery ,what testing requirement there are?
A:(1)battery test environment；
Temperature:23±2℃;
Relative humidity:60±20%RH;
Atmospheric pressure:86~106Kpa.
(2)Measuring instrumentation requirements
Voltage instrumentation requirements--Measuring the voltage meter accuracy no less than 0.5 magnitude;
Current instrumentation requirements--Measuring the current meter accuracy no less than 0.5 magnitude;
Time instrumentation requirements--Measuring the time meter accuracy no less than 0.1%;
Temperature instrumentation requirements--Measuring the temperature mater accuracy no less than 0.5℃
Impedance instrumentation requirement--Measuring impedance should by sinusoidal alternating(1 KHZ)test.
7.Q:What is full charged?
A:With charging voltage 4.2v,current 0.2C continued to charge the battery pack ,when charging current drops to 0.02C charging is terminated,shall be full charged.
8.Q:What is full discharged?
A :Standard discharge current 0.2C for continuous discharge is terminated,shall be full discharged.
