≥500 Times
1 year
CE/RoHS/UN38.3/MSDS
Credit Card.Paypal.TT.Escrow.Western Union
5.5*33*38 mm
cyclenpo
OEM&ODM
standard carton packaging or according to customer's special need
Product Specification
| NO. | Item | Specifications | |||
| 1 | Nominal capacity | 700mAh @ 0.2C Discharge | |||
| 2 | Initial Impedance | Pack ≤160mΩ | |||
| 3 | Weight | Approx：13g | |||
| 4 | Nominal voltage | 3.7V | |||
| Fully charge voltage (FC) | 4.2V Defined in this DOC: FC = 4.2V | ||||
| Fully discharge voltage | 2.4V Defined in this DOC: FD = 2.4V | ||||
| 5 | Charge current | 0.2C=40mA | Standard Charging | ||
| 0.5C=100mA | Rapid charge | ||||
| 6 | Standard charging method | 0.2C CC （ constant current ） charge to FC, then CV(constant voltage FC)charge till charge current decline to ≤0.01C | |||
| 7 | Charging time | 6.0 hours(Ref.) | Standard Charging | ||
| 2.5 至3.5hours(Ref.) | Rapid charge | ||||
| 8 | Max. charge current | Constant Current 0.5C Constant Voltage FC 0.01 C cut-off | |||
| 9 | Max. discharge current | Constant current 0.5C end voltage FD | |||
| 10 | Standard Discharge Current | Constant current 0.2 C end voltage FD | |||
| 11 | Charge cut-off voltage | Ref. 7.1 VDET1 | |||
| 12 | Discharge cut-off Voltage | Ref. 7.1 VDET2 | |||
|
13 |
Operating temperature | 0℃~45℃ | Charging | ||
| -20℃~60℃ | Discharging | ||||
| Storage temperature | -10℃~ +45℃ | less than 1 month | Recommended storage temperature: 25℃,at the shipment state | ||
| -10℃~ +35℃ | less than 6 months | ||||
| 14 | Recoverable capacity | Constant current 0.2C charge to FC, then constant voltage FC charge to current declines to 0.01C, rest for 10min，constant current 0.2C discharge to FD，rest for 10min.Repeat above steps 3 times, recording the maximum capacity | |||
| 15 | Storage Humidity | ≤75% RH | |||
| 16 | Appearance | Without distortion and leakage | |||
| 17 | Standard testing condition | Temperature ： 23±5℃
Humidity : ≤75%RH Atmospheric Pressure ： 86-106 Kpa |
|||
1.Q:Where can I get the price?
A:We usually quote within 24 hours after we get your inquiry.if you are very urgent to get the price,please call us or tell us in your inquiry priority.
2.Q:how can I get a sample to check your quality?
A:After price confirmation,you can require for samples to check our quality.
3.Q:What about the lead time for mass production?
A:It depends on your order quantity and the season you place the order.
4.Q:What is your team for payment?
A:We accept T/T,L/C,Paypal, Western Union,Money Gram,Ali Express,Cash,etc.
5.Q:What is accepted payment currency?
A:We accepted USD,EUR,CAD,AUD,HKD,GBP,JPY,NZD,SGD,CHF,THB,etc.
6.Q:If we went to test lithium polymer battery ,what testing requirement there are?
A:(1)battery test environment；
Temperature:23±2℃;
Relative humidity:60±20%RH;
Atmospheric pressure:86~106Kpa.
(2)Measuring instrumentation requirements
Voltage instrumentation requirements--Measuring the voltage meter accuracy no less than 0.5 magnitude;
Current instrumentation requirements--Measuring the current meter accuracy no less than 0.5 magnitude;
Time instrumentation requirements--Measuring the time meter accuracy no less than 0.1%;
Temperature instrumentation requirements--Measuring the temperature mater accuracy no less than 0.5℃
Impedance instrumentation requirement--Measuring impedance should by sinusoidal alternating(1 KHZ)test.
7.Q:What is full charged?
A:With charging voltage 4.2v,current 0.2C continued to charge the battery pack ,when charging current drops to 0.02C charging is terminated,shall be full charged.
8.Q:What is full discharged?
A :Standard discharge current 0.2C for continuous discharge is terminated,shall be full discharged.
