≥500 Times
1 year
CE/RoHS/UN38.3/MSDS
Credit Card.Paypal.TT.Escrow.Western Union
cyclenpo
OEM&ODM
customized
3-7days
| NO. | Item | Specifications | |
| 1 | Typical Capacity | 6360mAh @ 0.2C Discharge | |
| Minimum capacity | 6060mah @ 0.2C Discharge | ||
| 2 | Nominal voltage | 14.4V | |
| Rated Power | 91.584Wh | ||
| 3 | Charge | Max input voltage | 26V±0.05 |
| Max Charge voltage | 16.8V±0.05 | ||
| Standard charge current | 1272mA | ||
| Max Charge current | 6400mA | ||
| 4 | Discharge | Min Discharge voltage | 12.0±0.10V (PCB End-of-charge Voltage) |
| Standard discharge current | 0.2ItA 1272mA | ||
| Max continuous discharge current | 6.36 1.0ItA | ||
| Discharge cut-off voltage | 2.5V*n 10v | ||
| 5 | low voltage for discharge protection | 10v | |
| Initial Impedance | Max: 250mW | ||
| 6 | Weight | Approx：520g | |
| 7 | Operating temperature | Charging： 0℃~45℃
Discharging：-20℃~45℃ |
|
| 8 | Storage temperature | Within a months -5℃~35℃ | |
| Within 6 months -20～35℃ | |||
| 9 | Storage Humidity | ≤75% RH | |
| 10 | Appearance | Without scratch, distortion, contamination and leakage | |
| 11 | Standard environmental condition | Temperature ： 25±2℃
Humidity : 45-75%RH Atmospheric Pressure ： 86-106 KPA |
|
1.Q:Where can I get the price?
A:We usually quote within 24 hours after we get your inquiry.if you are very urgent to get the price,please call us or tell us in your inquiry priority.
2.Q:how can I get a sample to check your quality?
A:After price confirmation,you can require for samples to check our quality.
3.Q:What about the lead time for mass production?
A:It depends on your order quantity and the season you place the order.
4.Q:What is your team for payment?
A:We accept T/T,L/C,Paypal, Western Union,Money Gram,Ali Express,Cash,etc.
5.Q:What is accepted payment currency?
A:We accepted USD,EUR,CAD,AUD,HKD,GBP,JPY,NZD,SGD,CHF,THB,etc.
6.Q:If we went to test lithium polymer battery ,what testing requirement there are?
A:(1)battery test environment；
Temperature:23±2℃;
Relative humidity:60±20%RH;
Atmospheric pressure:86~106Kpa.
(2)Measuring instrumentation requirements
Voltage instrumentation requirements--Measuring the voltage meter accuracy no less than 0.5 magnitude;
Current instrumentation requirements--Measuring the current meter accuracy no less than 0.5 magnitude;
Time instrumentation requirements--Measuring the time meter accuracy no less than 0.1%;
Temperature instrumentation requirements--Measuring the temperature mater accuracy no less than 0.5℃
Impedance instrumentation requirement--Measuring impedance should by sinusoidal alternating(1 KHZ)test.
7.Q:What is full charged?
A:With charging voltage 4.2v,current 0.2C continued to charge the battery pack ,when charging current drops to 0.02C charging is terminated,shall be full charged.
8.Q:What is full discharged?
A :Standard discharge current 0.2C for continuous discharge is terminated,shall be full discharged.
