In addition to BMS protection, this 12-volt deep-cycle marine battery 240ah has a heating function and also has a built-in Bluetooth communication function, which can help you read the battery status from your computer or mobile phone APP.
>3000 times
175A
320A
3 years
CE/RoHS/UN38.3/MSDS
T/T,L/C,Paypal, Western Union,Money Gram,Ali Express,Cash,etc.
In addition to BMS protection, this 12v 200ah solar battery deep cycle marine battery 240ah has a heating and Bluetooth communication function, which can help you read the battery status from your computer or mobile phone APP.
Product Description
| NO | Item | General Parameter | Remark |
| 1 | Model | 12v200Ah | Single |
| 2 | Casing material for single cell | Nickel plated steel | |
| 3 | Standard capacity(0.2C5A) |
200Ah
|
|
| 4 |
Rated voltage
|
12.8V
|
3.20V(Work voltage:3.20V) |
| 5 | Max.Charge voltage |
14.6V
|
3.65V(Single Ave. charge Voltage) |
| 6 | Cut-off voltage |
10V
|
2.50V(Single Ave. Discharge Voltage) |
| 7 | Standard charge current | 30Ah |
0.2C
|
| 8 | Charging Time | About 5h | |
| 9 | Max Continuous discharge current |
175Ah
|
1.17C
|
| 10 | Peak discharge current |
320Ah
|
2.1C10seconds
|
| 11 | Battery dimension |
525±1*270±1*220±1mm
|
|
| 12 |
(Approx.)Total weight(Approx.)
|
About 23kg | |
| 13 | (Max, at 1000Hz.)Impedance(Max, at 1000Hz.) | ≤ 20mΩ | |
| 14 | (CC/CV)
Charge method (CC/CV) |
Standard | 0℃~45℃ |
| discharge |
-20℃~45℃
|
||
| storage |
-20℃~45℃
|
To relieve winter range anxiety in some freezing environment, the BMS can bring with self heating function. Resistance heating rapidly warms the inside of battery. Start heating temperature:≤0°C. Stop heating temperature:≥10°C. Can improve battery charge / discharge performance.
Widely used in RV, camping car, marine,boat,golf carts,sightseeing cars,solar backup,solar pv light and other lead acid replacement.
1.Where can I get the price of the lifepo4 bluetooth battery?
Welcome to contact the Online Services. If it's not our working time,
please click "Send Inquiry" above or "Leave a Comment" below,
We will offer you the best quote in 24 hours after we get the product specifications.
2.How can you guarantee your quality?
Normally we will send you a sample to confirm everything first.
We will make the big order exactly the same as you request.
3.What about the lead time for mass production?
It depends on your order quantity.Normally 1-2days if we have sample in stock,
5-7days for newly produced samples.10-20 day for big order.
4.What shipping method can I choose? How about the shipping time?
Express (3-7 working days), suitable for urgent time or small quantity.
Sea transportation (15-30 days), it suitable for mass production.
Air (4-7 days), from airport to airport.
