323*171*215 mm
about 12kg
≥3000times
3 years
CE/RoHS/UN38.3/MSDS
Credit Card.Paypal.TT.Escrow.Western Union
Lifepo4,also called lithium iron phosphate,is a new green battery material. With the advantages of high energy density, low self-discharge,long cycle life,small size and light weight, lifepo4 battery is gradually replacing lead acid and gel battery. It is more cost effective in long term consideration.
Whether you are looking for a standalone lithium battery, or whether you need us to customize a battery pack to certain specifications; we have the technology and expertise to deliver to your specifications.
|
Normal parameters
|
|||
|
NO
|
Item
|
General Parameter
|
Remark
|
|
1
|
Model
|
3.2V 35AH
|
Single
|
|
2
|
Casing Material for Single Cell
|
Nickel plated steel
|
|
|
3
|
Standard Capacity(0.2C5A)
|
100Ah
|
|
|
4
|
Rated Voltage
|
12.8V
|
3.20V(Work Voltage:3.20V)
|
|
5
|
Max.Charge Voltage
|
14.6V
|
3.65V(Single Ave. Charge Voltage)
|
|
6
|
Cut-off Voltage
|
10V
|
2.50V(Single Ave. Discharge Voltage)
|
|
8
|
Standard Charge Current
|
30A
|
0.5C
|
|
9
|
Charging Time
|
About 5h
|
|
|
10
|
Max Continuous Discharge Current
|
100A
|
1C
|
|
11
|
Peak Discharge Current
|
200A
|
2C (5s) |
|
12
|
Battery Dimension
|
328 * 171 * 215 mm
|
|
|
13
|
Total Weight (Approx.)
|
About 12kg
|
|
|
14
|
Impedance (Max, at 1000Hz.)
|
≤ 45mΩ
|
|
|
15
|
Charge method (CC/CV) |
Standard
|
0℃~65℃
|
|
discharge
|
-20℃~65℃
|
||
|
storage
|
-20℃~45℃
|
||
Features of 12v 100ah lifepo4 battery pack
1.Bulit in BMS.Provides overall protection and battery obtains independent balancing function.
2.Capable to deliever high discharge current. Max discharge current 175A,up to 320A.
3.Can be connected in series and parallel
4.Have passed different tests.No explosion,no smoke,no leakage.
5.Bluetooth function can be added to read battery status.
Application
Widely used in RV, camping car, marine,boat,golf carts,sightseeing cars,solar backup,solar pv light and
other lead acid replacement.
Performance Characteristic
Packing and Delivery
1.OEM&ODM manufacturer with various design and one-stop battery solution.
2.Reliable quality; Factory direct price; Complete production lines.
3.Timely and professional pre-sales service and after-sales service.
4.100% test before shipment; Solid package; Fast delivery and stable shipment.
1.Where can I get the price of 12v 100ah lifepo4?
Please click "Send Inquiry" above or "Leave a Comment" below
We will offer you the best quote in 24 hours after we get the product specifications
such as voltage capacity application etc
2.How can you guarantee your quality?
Normally we will send you a sample to confirm everything first.
We will make the big order exactly the same as you request.
3.What about the lead time for mass production?
It depends on your order quantity.Normally 1-2days if we have sample in stock,
5-7days for newly produced samples.10-20 day for big order.
4.What shipping method can I choose? How about the shipping time?
By Express (3-7 working days), suitable for urgent time or small quantity.
By Sea (15-30 days), it suitable for mass production.
By Air (4-7 days), from airport to airport.
