100A
Bluetooth&Self Heated Function
200A
>3000 times
3 years
CE/RoHS/UN38.3/MSDS
This lithium ion 12v 100ah is made of prismatic lifepo4 battery 3.2v 100ah (4s1p), lighter weight, higher power, longer life (>3000 cycle times) and much safer.The BMS not only provides the overall protection, but also brings with BLUETOOTH controlled function and SELF-HEATED function.It is ideal drop-in replacement for lead-acid batteries.
|
Item
|
General Parameter
|
Remark
|
|
Model
|
IFR 3.2V 100AH
|
Single
|
|
Casing material for single cell
|
Nickel plated steel
|
|
|
Standard capacity（0.2C5A）
|
100Ah
|
|
|
Rated voltage
|
12.8V
|
Work voltage：3.20V
|
|
Max.Charge voltage
|
14.6V
|
Single Ave. charge Voltage 3.65V
|
|
Cut-off voltage
|
10V
|
Single Ave. Discharge Voltage 2.5V
|
|
Standard charge current
|
50A
|
0.5C
|
|
Charging Time
|
About 5h
|
|
|
Max Continuous discharge current
|
100A or customized
|
1C
|
|
Peak discharge current
|
200A or customized
|
2C （5seconds）
|
|
Battery dimension
|
328±1*171±1*215±1mm
|
|
|
Total weight（Approx.)
|
About 12kg
|
|
|
Impedance（Max, at 1000Hz.）
|
≤ 45mΩ
|
|
|
Charge method (CC/CV) |
Standard
|
0℃～45℃
|
|
discharge
|
-20℃～65℃
|
|
|
storage
|
-20℃～45℃
|
Battery can add Bluetooth Function
Battery can add Self-heated Function
To relieve winter range anxiety in some freezing environment, resistance heating rapidly warms the inside of battery. Start heating temperature:≤0°C. Stop heating temperature: ≥10°C.
1. OEM&ODM manufacturer with various design and one-stop battery solution.
2. Reliable quality; Factory direct price; Complete production lines.
3. Timely and professional pre-sales service and after-sales service.
4. 100% test before shipment; Solid package; Fast delivery and stable shipment.
1.Where can I get the price of the lithium ion 12v 100ah battery?
Welcome to contact the Online Services. If it's not our working time,
please click "Send Inquiry" above or "Leave a Comment" below,
We will offer you the best quote in 24 hours after we get the product specifications
such as voltage capacity application etc.
2.How can you guarantee your quality?
Normally we will send you a sample to confirm everything first.
We will make the big order exactly the same as you request.
3.What about the lead time for mass production?
It depends on your order quantity.Normally 1-2days if we have sample in stock,
5-7days for newly produced samples.10-20 day for big order.
4.What shipping method can I choose? How about the shipping time?
By Express (3-7 working days), suitable for urgent time or small quantity.
By Sea (15-30 days), it suitable for mass production.
By Air (4-7 days), from airport to airport.
